5.10.3. Gap and Bezel Settings
ATTENTION! Always press the Apply changes button if you want to save the changes of the below
mentioned parameters.
DEFINITION: Gap means the physical distance between the edges of the display devices
DEFINITION: The Bezel
In certain cases, the dimensions of the sinks and the arrangement of the video wall requires special
devices) of the image:
No Gap (left) and Manually Set Gap (right)
▪ No Gap:
screens but the image looks a bit distorted.
▪ Dened Gap:
but the appearance of the overall image is more realistic.
The following parameters can be set:
▪ Display Size
▪ Bezel Settings
▪ Gap Settings
INFO:
5.10.4. Modifying a Video Wall
The Name of the Video Wall
Step 1. Press the Edit Video Wall button.
Step 2. Change the name of the video wall and press the Apply changes button.
Changing the Layout of the Decoders
Step 1. Press the Edit Video Wall button.
Step 1. Drag and drop a Decoder to the below indicated red colored (hidden) place; the device will be removed
from the wall.
Step 2. Another Decoder can be dragged and dropped to the empty place.
Step 3. Press the Apply changes button to save the settings.
ATTENTION!
new area show the original picture.
Changing the Gap and Bezel Settings
Step 1. Press the Edit Video Wall button.
Step 2. Apply
changes button the save the settings.
5.10.5. Deleting a Video Wall
Step 1. Select the video wall from the list.
Step 2. Click on the Delete video wall
pop-up window. The original image will be displayed on
all connected Decoders.
Gap Y
Width
Height
