2.7. Front Panel LEDs
INFO:
POWER LED
▪ OFF: the device is not powered.
▪ BLINKING: booting is in progress.
▪ ON: the device is powered on.
VIDEO LED
▪ OFF: there is no network connection.
▪ BLINKING: the device is connected to a network but there is no video stream in progress.
▪ ON: the device is connected to a network and video stream is in progress.
USB LED (only in Decoders)
▪ OFF: there is no USB transmission between the Encoder and the Decoder.
▪ ON: the USB transmission is active between the Encoder and the Decoder.
POWER and VIDEO LEDs (only in Encoders)
▪ BLINKING together: there is a Video Stream ID clash in the network, e.g. another Encoder is set to the
same Video Stream ID.
2.8. RJ45 LEDs
Left LED, Green Right LED, Yellow
Activity
LED state Left LED Right LED Function
Off Off No power
Solid green Solid red Dante is booting
Blinking green Solid green
Slave with sync
(normal operation)
Blinking green Blinking green
Clock master
(normal operation)
Blinking green Blinking red
Acquiring clock sync
(normal operation)
Alternating
Alternating
Identify
(blinking for 6 seconds)
Blinking red Blinking red Dante fail safe
Blinking amber Blinking amber Device is upgrading
