2. Product Overview
2.9. Front Panel Buttons
Audio Select Button #button
Toggle between the following modes:
Auto: the Analog audio input port is selected when a plug is connected.
Mode and Compression Mode Buttons
▪ Short press: switching between the Movie and Graphics modes.
▪ Long press (more, than 10 seconds): reset to factory default settings.
available in the Encoder:
▪ Movie mode
the available bandwidth. If the bandwidth is decreased the image quality will be lower, but the video
streaming is continuous.
▪ Graphics mode
bandwidth is decreased the image quality does not change, but frame drop may appear.
The setting has an affect when the available bandwidth is less than required.
AV Select Button
Toggle between the following modes:
▪ Auto mode:
input. If sync is lost for at least 3 seconds, it will be switched over to the other source. No automatic
switch back to the original input takes place when the signal is restored.
Connect and USB Connect Buttons
is necessary only in Multicast mode; when Unicast mode is active the assignment is arranged
automatically.
Audio Set Button
▪ Short press: the analog audio output volume is increased by 10%.
▪ Long pressthe analog audio output volume is set to 0%.
AUDIO
SELECT
Auto
HDMI+Embedded audio
HDMI+Analog audio
VGA+Analog audio
USB
CONNECT
AUDIO
SET
(VOLUME)
2.10. DIP Switch
switch values can be found in the DIP Switch States section; please see the examples below:
#led #dipswitch #videostreamid #streamid
DIP Switch State
Video Stream ID
DipSwitch value
Set by Value
8-4-2-1
STREAM ID
1 2 3 4
ON DIP
see the
built-in web
0x0
8-4-2-1
STREAM ID
1 2 3 4
ON DIP
1 0x1
8-4-2-1
STREAM ID
1 2 3 4
ON DIP
8 0x8
