6. Programmer's Reference VINX-1x0-HDMI Extenders – User's Manual 72

6.14. EDID Management (Encoder)

EDID memory can be found in the Multiviewer with Preview Images section.
6.14.1. 
Command and Response #edid
ç 
æ :E1
Parameters
 Parameter description Parameter values
 The EDID memory location F1-F132: Factory preset EDIDs
U1-U5: User presets
D1: The EDID of the Display Device at the local output
E1 means the Emulated EDID memory location (Input port).
INFO:  There are empty slots in the Factory EDID range for future developments. See the 
section.
Example
ç 
æ 
Explanation

6.14.2. Setting the Emulated EDID on the Input Port
Command and Response
ç <source>:<destination>)
æ 
Parameters
 Parameter description Parameter values
<source> Source EDID memory
location
F1-F132: Factory preset EDIDs
U1-U5: User presets
D1: The EDID of the Display Device at the local output
<destination> The emulated EDID
memory of the input port
E1
Example
ç 
æ 
6.14.3. Copying an EDID
Command and Response
ç <source>:<destination>)
æ 
Parameters
 Parameter description Parameter values
<source> Source EDID memory location F1-F132: Factory preset EDIDs
U1-U5: User presets
D1: The EDID of the Display Device at the local output
<destination> The desired User EDID location U1-U5
Example
ç 
æ 
Explanation
The EDID of the last connected sink (HDMI output, D1) has been copied to U1 User memory slot.
6.14.4. 
Command and Response
ç .PreferredResolution
æ <Resolution>
Parameters
 Parameter description Parameter values
 The desired EDID memory
type
F: Factory preset EDIDs
U: User presets
D: EDID from a connected display device
E: Emulated EDID
 The desired EDID memory
location
F1-F132: Factory preset EDIDs
U1-U5: User presets
D1: The EDID of the Display Device at the local output
E1: The emulated EDID at the input
<Resolution> The preferred resolution in
the indicated format
<width>x
: p (progressive), i (interlaced)
Example
ç 
æ 
INFO:  Use the Manufacturer property to query the manufacturer and the MonitorName property to query the
name of the monitor.




