3. Installation VINX-1x0-HDMI Extenders – User's Manual 22

3.1.3. UD-kit Mounting
WARNING!  
may touch internal parts and harm the device.
Mounting with UD-kit double (Under Desk Double)
INFO:  
More details about the accessories and the mounting can be found in the Mounting Assembly Guide.
3.2. Mounting into the Powered Rackmount Cage
DIFFERENCE:  Only the VINX-110-HDMI-ENC and VINX-120-HDMI-DEC devices are compatible with the


3.2.1. Features
▪ 16 slots for VINX devices in any combination.
▪ Built-in power supply unit for the devices.
▪ Easy to install as the cage is rack mountable: 3U-high, 1U-wide.
▪ 
▪ The structure of the cage allows different arrangements not only for VINX devices.
Rackmount Cage.
3.2.2. Assembling Steps
Step 1. Assembling the extender bracket.
Fasten the mounting bracket (highlighted with grey) onto the bottom


Required screw:





