LM Trac 287 - Page 57

LM 287 User Manual – 30.10.2023
57
Figure 70
Position
Function
K301
A frame lifting
K302
A frame lowering
K303
Cylinder hydraulic 1
K304
Cylinder hydraulic 1
K305
Left joystick front button (optional function)
K306
Bonnet / platform body lifting (optional accessory)
K307
Cylinder hydraulic 3
K308
Cylinder hydraulic 3
K309
Cylinder hydraulic 2
K310
Cylinder hydraulic 2
K311
Bonnet / platform body lowering (optional accessory)
K312
Immobilizer (sensor, motor hydraulics in use)
