Maintenance...Maintenance of the centering/blocking system zone
5-100
LTO
5.6.3 REPLACING THE MAIN FUSE
To replace a fuse, proceed as follows:
CAUTION
STRICTLY OBSERVE THE FOLLOWING INSTRUCTIONS. FAILURE TO DO SO CAN BE DANGE-
ROUS BOTH FOR THE USER AND THE MACHINE.
#1 Switch OFF the machine if it is ON.
#2 Disconnect the power cord from the wall socket.
#3 Remove the rear cover.
#4 Remove the fuse from the fuse holder on the left of the mains socket of the
machine.
#5 Fit a new fuse (see Technical specifications, chapter 7.4) in its housing.
#6 Put back the rear cover.
#7 Connect the machine power cord to the wall socket.
