Luneau Technology Briot perception2 - Produce a Manual Bevel

Using your Edger...Special case
3-73
LTO
3.3.3.5 PRODUCE A MANUAL BEVEL
3.3.3.5.1 SITUATION
 You wish to visualise the lens thickness and adjust the finishing position.
3.3.3.5.2 PROCEDURE
To produce a manual bevel:
1. Load or create a job.
2. Enter its characteristics.
3. Proceed as shown on the flow chart.
3.3.3.5.3 IMPORTANT NOTES
 The maximum distance between the apex of the bevel and the front face is 5 mm.
 If you wish to reposition the whole bevel, move the bevel apex in one direction to the required position. 
Then do the same from the opposite point.
 To make a safety-bevel of any type, the minimum distance between the bevel apex and the front/rear face
must be greater than 1.6 mm. If it is less than 1.6 mm at any point of the lens, the safety-bevel will not be
produced at this point.
3.3.3.5.4 LIMITS
 If the maximum thickness of the lens is less than 2 mm, the applied bevel will automatically be of 50% type,
whichever type of bevel is selected initially.
3.3.3.5.5 RETOUCH
 When the edging cycle is finished, remove the lens from the edging chamber without removing the block
so as to be able to retouch it if necessary.
 Check the lens dimensions and finishing.
