6.2.2 OPERATION OF THE OTHER SCREENS
6.2.2.1 PRESENTATION
The following screen corresponds to the solenoid valve and pump tests:
Screen 6-2: Test screen
6.2.2.1.1 SCREEN WITH SWITCH
To start the test, press the switch of the element you wish to test.
Observe the test.
To stop the test, press the switch again.
6.2.2.1.2 SCREEN WITH MICRO-SWITCHES AND PHOTOCELLS
Manually operate the micro-switch or photocell of the element you wish to test.
Observe the status of the micro-switch or photocell on the screen.
Spraying
of edgers
and visor
Spraying
Rear of edging
chamber
Start-up of
edgers
(visor closed)
Pump
Exit
Micro-
switches
To Next Page
