Maintenance...Regular maintenance of the edger
5-110
LTO
5.7.6 CLEANING THE FILTERS AND WATER TANK
Refer to the document FC00854.
5.7.7 EMPTYING THE WATER TANK
5.7.7.1 PRELIMINARY REMARKS
Use a standard discharge pipe with a 20x27 connection.
5.7.7.2 PROCEDURE
To empty the settling tank, follow the procedure below:
Flow chart 5-5: Emptying the settling tank
#1 Fit a discharge pipe on the same side as the valve and connect it to the
drainage system (bucket, sink, drain etc.).
#2
#3
#4
#5
#6 Open the discharge valve.
#7 Close the discharge valve when the settling tank is empty.
#8
#9 x 3
#10 Disconnect the discharge pipe and put it away.
