3.1 PRESENTATION
3.1.1 PRESENTATION OF THE MACHINE
 GENERAL ILLUSTRATION
The illustration below (Illustration 3-1) is an overall view of the machine (emotion2 or perception2) and shows
its main parts.
Illustration 3-1 : Overall view of the edger
* On the Perception2 machine, the Scanform is replaced by a map pockets.
 MAIN PARTS
The exploded view below (Illustration 3-2) shows the main parts of the edger.
Illustration 3-2 : Exploded view of the edger
Touch screen
Centering/blocking system
Edging
chamber
ScanForm*
Edging chamber
Electronic system
Carriage
Scanform
Safety-bevel grooving drilling
system
Screen
Centering/blocking 
system
