Follow the steps below to adjust the glass roughing size:
Flow chart 5-9: Adjustment of the mineral roughing size
#1
#2
#3
#4 Centre and block a glass lens.
#5 Fit the lens clamping and lens holder adaptors on the shafts.
Place the lens in the edging chamber and tighten it.
#6 

#7 Measure the diameter of the lens with a caliper.
#8 

#9 

#10 

#11 x 3
