5-26
Application Manual CDA3000
5 Software functions
Device-dependent torques for scaling (204-TSCL)
Device type
Power
[kW]
Torque for scaling
Value range for
204-TSCL
BV
[Nm]
CDA32.003 0.375
0.05 ... 200 % of BV
5
CDA32.004 0.75 10.2
CDA32.006 1.1 15
CDA32.008 1.5 20
CDA34.003 0.75 10.2
CDA34.005 1.5 20
CDA34.006 2.2 30
CDA34.008 3 40
CDA34.010 4 54
CDA34.014 5.5 72
CDA34.017 7.5 98
CDA34.024 11 144
CDA34.032 15 196
CDA34.045 22 288
CDA34.060 30 392
CDA34.072 37 480
CDA34.090 45 584
CDA34.110 55 712
CDA34.143 75 968
CDA34.170 90 1162
BV: Device-dependent base value
Table 5.15 Torque scaling values for various device power classes
