Lust CDA3000 - Page 142

5-28
Application Manual CDA3000
5 Software functions
Settings for FIS00 ... 214-FIE00 ... 223-FIF1
221-FIE07 Function selector digital input of user module
IED07
-”- OFF

222-FIF0 Function selector virtual digital fixed input 0 -”- OFF

223-FIF1 Function selector virtual digital fixed input 1 -”- OFF

1)
Switch between FMSI and simple input functions does not work online
Parameter Function Value range FS Unit Online
Table 5.16 Parameters from subject area _21ID Digital inputs
Explanatory notes
• The analog inputs ISA00 and ISA01 can also be assigned digital
functions (see section 5.2.1).
• Selectors FIF0 and FIF1 provide two virtual inputs with the fixed
value1(Highlevel).Theycanbeusedinplaceofapermanently
active switch.
BUS KP/ DM Function Effect
F
I
S
0
0
F
I
S
0
1
F
I
S
0
2
F
I
S
0
3
F
I
E
0
x
F
I
F
x
0 OFF No function Input off
     
1 STR Start clockwise Start enable for motor clockwise running
   
2 STL Start anti-clockwise Start enable for motor anti-clockwise run-
ning
   
3 INV Reverse direction Reference is inverted, causing a reversal of
direction
     
4 /STOP /Emergency stop via stop ramp Stop ramp is executed dependent on active
characteristic data set (CDS).
Attention: Signal inverted ( / )
(section 5.5.3 “_59 DP-Driving profile
generator”)
     
5 SADD1 Offset for reference selector 280-
RSSL1
Reference selector 280-RSSL1 is offset by
the value in 289-SADD1 to a different refer-
ence source.
(section 5.2.6 “_28 RS-Reference struc-
ture”)
     
Table 5.17 Settings of the function selectors
