5-100
Application Manual CDA3000
5 Software functions
Setting of inputs for MOP functions
Note: In terminal operation the function selector of one digital or
one analog input (in digital function) is configured with
MP-UP = increase reference
MP-DN = reduce reference
(see section 5.2 “Inputs and outputs”).
2F2
Increase and reduce speed within limits FMINx ... FMAXx with inputs MP_UP
and MP_DN. If both inputs are set simultaneously, the offset speed is reset to
0 Hz.
3F3
Increase and reduce speed within limits FMINx ... FMAXx with inputs MP_UP
and MP_DN. In case of failure of the mains voltage the offset speed is stored.
4F4
Increase and reduce speed within limits FMINx ... FMAXx with inputs MP_UP
and MP_DN. If both inputs are set simultaneously, the offset speed is reset to
0 Hz. In case of failure of the mains voltage the offset speed is stored.
5F5
Increase and reduce speed within limits FMINx ... FMAXx with inputs MP_UP
and MP_DN. The offset speed is reset to 0 Hz when the start command is
cancelled.
6F6
Increase and reduce speed within limits FMINx ... FMAXx with inputs MP_UP
and MP_DN. If both inputs are set simultaneously, the offset speed is reset to
0 Hz. The offset speed is reset to 0 Hz when the start command is cancelled.
Definitions
Base value Analog speed reference set at input ISAxx
Offset Portion of the increase or decrease in the base value, influenced
by the inputs with the functions MP_UP and MP_DN
ISDxx = MP_UP Offset input for reference increase
ISDxx = MP_DN Offset input for reference decrease
BUS KP/DM Function
Table 5.61 Settings for 320-MPSEL MOP function
