Lust CDA3000 - Page 25

Application Manual CDA3000
2-11
2 Inverter module CDA3000
1
2
3
4
5
6
A
DE
EN
FR
DE
EN
FR
Note: The sampling time of the inputs and outputs is 1 ms. The
digital voltages relate to the digital ground and the analog
voltages to the analog ground.
In the range >5 V to <18 V DC the response of the digital
inputs is undefined.
1) Applicable to limited degree
Voltage supply
+10.5V X2-1 • Auxiliary voltage U
R
=10.5 V DC
• Short-circuit proof
• I
max
= 10 mA
–
+24V X2-6
X2-7
X2-13
• Auxiliary voltage U
V
= 24 V DC
• Short-circuit proof
• I
max
= 200 mA (overall, also includes the
driver currents for outputs OSDox)
• No polarity reversal protection

Analog ground
AGND X2-4 • Isolated from DGND
Digital ground
DGND X2-14
X2-17
• Isolated from AGND
Des.
Ter-
minal
Specification Floating
Table 2.6 Specification of control terminals
