Application Manual CDA3000
4 Application data sets
(1) Analog reference value of ISA00
Figure 4.32 Example of use of emergency operation independently of bus
operation ASTER = BUS_3
The mode of functioning of the limit switch evaluation is shown in Figure
4.9 and Figure 4.10 in section 4.3.3 “DRV_3”.
t [ms]
0
f [Hz]
v [m/s]
0
1
0
1
S1
STR
0
1
STL
590-ACCR1
590-ACCR1
590-ACCR1
(1)
594-STPR1
592-DECR1
(1)
(1)
