262335 68 Revision A
Figure 3.126: Driveshield – Headers Sold outside
North America
4. Headers sold outside North America: Insert a tool into
hole (A) and pry to release latch (B). Disengage rubber
latch (C) and open driveshield (D).
Figure 3.127: Driveshield Open
The driveshield is shown in the open position.
