262335 87 Revision A
Figure 3.163: Left Platform
13. Push latch (A) to unlock platform (B).
Figure 3.164: Left Platform
14. Pull platform (A) toward the cab until it stops and the latch
is engaged.
15. If this is the first time the header is connected to the
windrower, calibrate the header. For instructions, refer to
the windrower operator’s manual.
ASSEMBLING THE MACHINE
