MacDon D65 - Page 103

214327 83 Revision B
To deliver crop from the right end, move the decks to the left end of the header as follows:
1004216
A
Figure 3.75: Right Deck Shown
2. Loosen bolt (A) on the right deck.
3. Slide the deck to close off the center opening. Tighten
bolt (A).
10046951004695
A
Figure 3.76: Right Deck Motor
4. Reverse draper drive motor hoses (A) on the moved deck
so that the draper turns the same direction as the
unmoved deck.
NOTE:
Loosen the clamp on the plastic sleeve at the drive motor
so that hoses (A) can be reversed. Tighten the clamp.
NOTE:
To deliver crop from the left end, move the decks to the
right end of the header following the steps above.
OPERATION
