ü
Draper seal
ü
Reel drive chain tension
ü
Reel tine/cutterbar
clearance
ü
Knife drive belt tension
ü
Wheel bolt torque
ü
Knife drive box
lubricant level
ü
Knife drive box
mounting bolts
S
Reel drive chain
Maintenance
Record
Action:
üü - Check
SS - Lubricate
▲▲ - Change
250 Hours or Annually
46
ü
Draper seal
S
Reel drive U-joint
S
Transport axle pivot
bushings
500 Hours or Annually
46
ü
Draper seal
S
Reel shaft bearings
S
Stabilizer/slow speed
transport wheel bearings
1000 Hours or 3 Years
46
▲
Knife drive box lubricant
5.3.2 Break-In Inspection
Break-in inspections involve checking belts, fluids, and performing general machine inspections for loose hardware or other
areas of concern. Break-in inspections ensure that all components can operate for an extended period without requiring
service or replacement.
Inspection
Interval Item Refer to
5 hours
Check for loose hardware.
Tighten to required torque.
8.2 Torque Specifications, page 270
5 hours
Check knife drive belts tension.
Periodically check for first 50 hours.
• Tensioning Timed Knife Drive Belts, page 170
• Tensioning Untimed Knife Drive Belts, page 165
10 hours
Check knife drive box mounting bolts.
Checking Mounting Bolts, page 155
50 hours
Change knife drive box lubricant. Changing Oil in Knife Drive Box, page 162
5.3.3 Maintaining the Header – Preseason
Equipment should be inspected and serviced at the beginning of each operating season.
Perform the following procedures at the beginning of each operating season:
MAINTENANCE AND SERVICING
