6.2 Cutterbar
6.2.1 Cutterbar Wearplate
Cutterbar wearplates are recommended for cutting on the ground when the soil is adhering to the steel.
Figure 6.6: Cutterbar Wearplates
Installation instructions are included in the kit.
Order one of the following bundles according to your
header size:
• 4.6 m (15 ft.) – MD #B4864
• 6.1 m (20 ft.) – MD #B4865
• 7.6 m (25 ft.) – MD #B4838
• 9.1 m (30 ft.) – MD #B4839
• 10.7 m (35 ft.) – MD #B4840
• 12.2 m (40 ft.) – MD #B4841
6.2.2 Knifehead Shield
Knifehead shields attach to the endsheets and reduce the knifehead opening to prevent cut crop (particularly severely
lodged crop) from accumulating over the knifehead and damaging the knife drive box and endsheet.
Figure 6.7: Knifehead Shield
Installation instructions are included in the kit.
Order the following bundles according to your header size and
guard type:
Regular Guards
• 9.1 m (30 ft.) and larger – MD #220101
Stub Guards
• 9.1 m (30 ft.) and larger – MD #220103
