214327 247 Revision B
6.2.3 Stub Guard Conversion Kit
Stub guards, complete with top guides and adjuster shoes, are designed to cut tough crops.
Figure 6.8: Stub Guards
Installation and adjustment instructions are included in the kit.
Order one of the following bundles according to your
header size:
• 4.6 m (15 ft.) – MD #B5009
• 6.1 m (20 ft.) – MD #B5010
• 7.6 m (25 ft.) – MD #B5011
• 9.1 m (30 ft.) – MD #B5012
• 10.7 m (35 ft.) – MD #B5013
OPTIONS AND ATTACHMENTS
