214327 249 Revision B
6.3.3 Stabilizer / Slow Speed Transport Wheels
Stabilizer/slow speed transport wheels help to stabilize the header in field conditions that would otherwise cause the
header to bounce, resulting in uneven cutting heights.
Figure 6.11: Stabilizer/Transport Wheels
This system is similar to the Stabilizer Wheel option. For more
information about that option, refer to 6.3.2 Stabilizer Wheels,
page 248.
Stabilizer/slow speed transport wheels are used to convert the
header into transport mode for slow-speed towing behind a
properly configured windrower (or agricultural tractor). A tow
pole and installation instructions are included in the kit.
This option is available for use with 9.1, 10.7, and 12.2 m (30,
35, and 40 ft.) headers.
MD #C1997
OPTIONS AND ATTACHMENTS
