214327 251 Revision B
6.4.3 Draper Clips
Draper clips offer additional wear protection for the draper cleats. They may prove useful in situations where conditions
are dry or consistently hot.
Figure 6.14: Draper Clips
Installation instructions are included with the kit.
• MD #294859 for square cleats (A) (for drapers MD #172195, MD #172196, MD #172197, MD #172198)
• MD #294858 for tapered cleats (B) (for drapers MD #220635, MD #220636, MD #220637, MD #220638, MD #220639,
MD #220640)
6.4.4 Rice Divider Rods
Figure 6.15: Rice Divider Rod
Rice divider rods attach to the left and right crop dividers and
divide tall and tangled rice crops in a similar manner to standard
crop divider rods performing in standing crops. Installation
instructions are included in the kit.
MD #B5609
OPTIONS AND ATTACHMENTS
