Figure 5.7: Every 50 Hours – Upper Cross Auger, New Assembly
A- Right End Bearing
B - Two-Piece Auger Only: Upper Cross Auger U-joints [Two places, accessible by opening cover (D)]
C - Two-Piece Auger Only: Upper Cross Auger Sliding Hubs [Two places, accessible by opening cover (D)]
E - Two-Piece Auger Only: Upper Cross Auger Center Bearings (Two Places)
