214327 129 Revision B
Figure 5.9: Every 100 Hours
ϭϬϯϵϴϰϱ
D
B
A
C
A - Knife Drive Box (Check Oil Level Between Lower Hole and End of Dipstick [B]) C - Reel Drive Chain (1 Place) (Double Reel Shown – Single Reel Similar)
D - Hydraulic Couplers (Use WD40
®
or Equivalent)
MAINTENANCE AND SERVICING
