214327 131 Revision B
Figure 5.11: Every 500 Hours
1010062
D
C
A
B
A - Reel Right Bearing (1 Place) B - Reel Center Bearing (1 Place)
C - Wheel Bearings (4 Places) D - Reel Left Bearing (1 Place)
MAINTENANCE AND SERVICING
