MacDon D65 - 5.6 Knife Drive; 5.6.1 Knife Drive Box; Checking Mounting Bolts

214327 135 Revision B
1012796
A
B
Figure 5.19: Drive Cover – Double Reel
3. Remove three bolts (A) and remove lower cover (B) if
necessary.
1004752
A
Figure 5.20: Drive Chain
4. Apply a liberal amount of grease to chain (A).
1012796
A
B
Figure 5.21: Drive Cover – Double Reel
5. Position lower drive cover (B) onto the reel drive (if
previously removed) and secure with three bolts (A).
MAINTENANCE AND SERVICING
