MacDon D65 - Page 35

214327 15 Revision B
E
F
ϭϬϯϵϴϭϳ
A
B
C
D
C
E
A
D
C
B
F
Figure 1.23: Backtube – 12.1 m (40 ft.) Rigid Header
A - MD #184372 B - MD #131392 C - MD #131391 D - MD #166466
E - MD #184372 (One-piece frame only) F - MD #184372 (Split frame only)
SAFETY
