Table 3.2 Recommended Header Settings
Crop
Condition
Divider
Rods
Header
Angle
6
Knife
Speed
7
Reel Tine
Pitch
8
Reel Speed
%
9
Reel
Fore-
Aft
10
Skid Shoe
Position
11
Stabilizer
Wheels
12
Upper Cross
Auger
Float
N (lbf)
13
Crop Type: Cereals Stubble Height: <102 mm (<4 in.)
Light
On 0–3
Medium
2
10–15 6 or 7
Up or center
Variable
Not required
311 (70)
Normal
On 0–3
High
2
10 6 or 7
Up or center
Variable
Not required
311 (70)
Heavy
On 4–7
High
2
10 6 or 7
Up or center
Variable
Not required
311 (70)
Lodged
On 4–7
High
35–10
4or5
Up or center
Variable
Not required
311 (70)
Crop Type: Cereals Stubble Height: 102–203 mm (4–8 in.)
Light
On 0–3
Medium
2
10–15 6 or 7
Center or down Variable
Not required
311 (70)
Normal
On 0–3
High
2
10 6 or 7
Center or down Variable
Not required
311 (70)
Heavy
On 4–7
High
2
10 6 or 7
Down
Variable
Not required
311 (70)
Lodged
On 4–7
High
35–10
4 or 5 Down
Variable
Not required
311 (70)
OPERATION
6. Set header angle as shallow as possible with center-link and skid shoes while maintaining cutting height. For instructions, refer to Controlling Header Angle,
page 57.
7. Refer to 3.7.9 Knife Speed, page 59. 8. Refer to Reel Cam Settings, page 68. 9. Percentage above ground speed. Refer to 3.7.6 Reel Speed, page 58. 10. Refer to 3.7.11 Reel Fore-Aft Position, page 61. 11. Skid shoe position is used in combination with header angle to determine the cutting height when cutting on or very close to the ground. Refer to 3.7.1
Cutting Height, page 52.
12. Stabilizer wheels are used to limit the side-to-side movement when cutting off the ground in rolling terrain, and to minimize bouncing. 13. Force required to lift header at ends. Refer to your windrower operator’s manual for adjustment procedures.
