MacDon D65 - Page 68

214327 48 Revision B
Table 3.2 Recommended Header Settings (continued)
Crop
Condition
Divider
Rods
Header
Angle
30
Knife
Speed
31
Reel Tine
Pitch
32
Reel Speed
%
33
Reel
Fore-
Aft
34
Skid Shoe
Position
35
Stabilizer
Wheels
36
Upper Cross
Auger
Float
N (lbf)
37
Crop Type: Edible beans Stubble Height: On ground
Light
Off
8–10
Medium
25–10 3 or 4
Up or center
Storage
Not required
445 (100)
Normal
Off
8–10
Medium
2
5–10 3 or 4
Up or center Storage
Not required
445 (100)
Heavy
Off
8–10
Medium
2
5–10 3 or 4
Up or center
Storage
Not required
445 (100)
Lodged
Off
8–10
Medium
35–10 3 or 4
Up or center
Storage
Not required
445 (100)
Crop Type: Grass Stubble Height: On ground
Light
On
Variable
High
2
10 6 or 7
Up or center Storage
Not required
311–445
(70–100)
Normal
On
Variable
High
2
10 6 or 7
Up or center Storage
Not required
311–445
(70–100)
Heavy
On
Variable
High
2
10 6 or 7
Up or center Storage
Not required
311–445
(70–100)
Lodged
On
Variable
High
2
10–15 6 or 7
Up or center Storage
Not required
311–445
(70–100)
OPERATION
30. Set header angle as shallow as possible with center-link and skid shoes while maintaining cutting height. For instructions, refer to Controlling Header Angle,
page 57.
31. Refer to 3.7.9 Knife Speed, page 59. 32. Refer to Reel Cam Settings, page 68. 33. Percentage above ground speed. Refer to 3.7.6 Reel Speed, page 58. 34. Refer to 3.7.11 Reel Fore-Aft Position, page 61. 35. Skid shoe position is used in combination with header angle to determine the cutting height when cutting on or very close to the ground. Refer to 3.7.1
Cutting Height, page 52.
36. Stabilizer wheels are used to limit the side-to-side movement when cutting off the ground in rolling terrain, and to minimize bouncing. 37. Force required to lift header at ends. Refer to your windrower operator’s manual for adjustment procedures.
