Maintenance work on the carrier
7.5 Exhaust system with exhaust emission control
03.11.2017
Maintenance manual 3 302 574 en 7 - 41
GMK3060
Filling up • Find out about filling up in the operating manual and note the warnings;
à Operating Instructions.
• Fill the AdBlue tank via the filler neck (1) and
close it using the cap.
• Secure the cap with the retaining pin (2).
• Check the filling level on the CCS display (3);
à p. 7 - 40.
7.5.3 Check the exhaust system for external damage
Spare parts
and tools
Prerequisites – The engine must not be running and must be secured against unauthor-
ised use;
à p. 2 - 3.
– The engine and the exhaust system must be cool.
s
G
Danger of scalding due to ammonia vapours!
Ammonia vapour can escape if the AdBlue tank is opened when the outside
temperature is high. Ammonia vapours can irritate mucous membranes,
skin and eyes.
Ensure that there is adequate fresh air supply and do not breathe in the
escaping ammonia vapours.
Designation Quantity GROVE part no.
Entire exhaust system (kit)
– DOC catalytic converter + DPF particle
filter
– AdBlue mixing tube
– SCR catalytic converter
1
1
1
1
04192288
04180232
04168809
04180235
