Manitowoc GROVE GMK 3060 - Lubricating the Auxiliary Hoist

Maintenance work on the superstructure
8.3 Hoists
03.11.2017
Maintenance manual 3 302 574 en 8 - 11
GMK3060
8.3.4 Lubricating the auxiliary hoist
Grease, spare
parts, tools
– Grease gun from the tool set.
Prerequisites – The engine must not be running and must be secured against
una
uthorised use;
à p. 2 - 3.
Greasing
• Clean the grease nipple (1) and lubricate the
hoist at the grease nipple.
• Remove any grease that emerges.
M 6
Lubricating
grease
Designation
to DIN 51502
Specification
Classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
S
Risk of damage to the auxiliary hoist!
The auxiliary hoist drum bearing is not automatically lubricated by the
distributor on the turntable.
Lubricate the auxiliary hoist drum bearing with the grease gun at the
lubricating nipple.
