Manitowoc GROVE GMK 3060 User Manual

Maintenance work on the superstructure
8.8 Hoist ropes
03.11.2017
Maintenance manual 3 302 574 en 8 - 57
GMK3060
H
Observe the hook block when unreeling.
The hook block must not rotate!
• Adjust the lowering limit switch; à p. 8 - 57.
• Run in the new rope with small loads so that the rope can settle on the
hoist drum.
8.8.6 Adjusting the lowering limit switch
A lowering limit switch is mounted both on the main hoist and on the
auxiliary hoist.
Spare parts
and tools
Prerequisites – A hook block mu
st be reeved 5-fold;
à Operating Instructions.
– The main boom is fully raised and extended;
à Operating Instructions.
– The hook block is lowered until only 3 turns of the rope remain on the
hoist drum.
s
G
Risk of accidents if the lowering limit switch is set incorrectly!
After inserting a new rope, the lowering limit switch must always be reset.
In this way you avoid the lowering limit switch switching off too late or not
at all, the rope being damaged and the load being dropped.
Designation Quantity GROVE part no.
Cover gasket 2 02315305

Manitowoc GROVE GMK 3060 Specifications

General

Brand	Manitowoc
Model	GROVE GMK 3060
Category	Construction Equipment
Language	English
