Maintenance work on the carrier
7.3 Engine
7 - 24 3 302 574 en Maintenance manual
GMK3060
03.11.2017
7.3.7 Changing the oil and oil filter
Oil, spare parts,
tools
– Receptacle, approx. 30 l (8 gal);
à p. 2 - 4.
Prerequisites
• Find out the prescribed oil specifications and about the need to shorten
the maintenance interval under special operating conditions;
à Engine manufacturer’s documentation.
• Find out about the safety instructions and the sequence of steps to change
the oil and the oil filter;
à Engine manufacturer’s documentation.
– The truck crane must be level.
– The engine must not be running and must be secured against unauthor-
ised use;
à p. 2 - 3.
Changing
M 6
Engine oil
in litres (gal)
Designation
to DIN 51502
Specification
Classification
GROVE part no.
26.5 (7.0) HD - CD CES 20081
Cummins
SAE 15 W-40
04162428
Designation Quantity GROVE part no.
Gasket for oil drain plug 1 03042026
Oil filter 1 04182152
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any
consumables that escape.
Store/dispose of consumable
s and any soaked equipment properly.
Ask about the applicable regulations.
