Manitowoc GROVE GMK 3060 - Central Lubrication System; Checking the Filling Level

Maintenance work on the superstructure
8.10 Central lubrication system
03.11.2017
Maintenance manual 3 302 574 en 8 - 63
GMK3060
8.10 Central lubrication system
Connected lubricating points:
– Main hoist drum,
– Ball slewing bearing,
– Telescopic boom – pivot pins,
– Derricking cylinder – pivot pin.
Lubricating points not connected:
– Auxiliary hoist drum;
à p. 8 - 11.
8.10.1 Checking the filling level
Grease, spare
parts, tools
Prerequisites – The engine must not be running and must be secured against
unauthorised use;
à p. 2 - 3.
s
W
Lubricating
grease
Designation
to DIN 51502
Specification
Classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
Designation Quantity GROVE part no.
Manual filling pump
(in the tool set supplied)
1
03320403
