Maintenance work on the carrier
7.4 Fuel system
03.11.2017
Maintenance manual 3 302 574 en 7 - 35
GMK3060
7.4.2 Replacing fuel filter 1
Spare parts
and tools
– Receptacle, approx. 5 l (1.5 gal);
à p. 2 - 4.
Prerequisites – The truck crane must be level.
– The engine must not be running and must be secured against unauthor-
ised use;
à p. 2 - 3.
– If the fuel is dirty: Reduce the maintenance interval.
Changing
• Place a receptacle underneath the filter.
• Open the screw (1) and the valve (2) and
drain the consumable.
s
Designation Quantity GROVE part no.
Filter 1 04182148
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any
consumables that escape.
Stor
e/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
