Manitowoc GROVE GMK 3060 User Manual

Maintenance work on the carrier
7.7 Axle lines
03.11.2017
Maintenance manual 3 302 574 en 7 - 53
GMK3060
7.7.3 Axle centre drives – changing the oil
Oil, spare parts,
tools
1)
Additional equipment (1st axle line driven)
– Receptacle, approx. 20 l (5.0 gal);
à p. 2 - 4.
Prerequisites – The truck crane must be raised on outriggers or parked over an inspection
pit.
– The engine must not be running and must be
secured against unauthor-
ised use;
à p. 2 - 3.
s
M 12
Gear oil
in litres (gal)
Designation
to DIN 51502
Specification
Classification
GROVE part no.
Axle lines 1+3:
13.0 (3.5) each
Axle line 2:
16.2 (4.3)
C - LPF MIL-L 2105 B
API-GL-5
Viscosity:
Hyp SAE 90
ISO - VG 220
00552891
for drive Designation Quantity GROVE part no.
6 x 4 x 6
Gasket 30 x 36 Cu DIN 7603
2 00117151
Gasket 24 x 29 Cu DIN 7603 1 00117145
Gasket 36 x 42 Cu DIN 7603 2 01371208
Gasket 16 x 20 Cu DIN 7603 1 00117134
6 x 6 x 6
1)
Gasket 30 x 36 Cu DIN 7603 3 00117151
Gasket 24 x 29 Cu DIN 7603 1 00117145
Gasket 36 x 42 Cu DIN 7603 3 01371208
Gasket 16 x 20 Cu DIN 7603 1 00117134
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any con-
sumables that escape.
Store/dispose of consumables and any so
aked equipment properly.
Ask about the applicable regulations.
