Maintenance work on the carrier
7.7 Axle lines
7 - 52 3 302 574 en Maintenance manual
GMK3060
03.11.2017
1st and 3rd axle
line
Axle centre drive on the 1st Axle line only present with a 6 x 6 x 6 drive.
• Unscrew the screw (1).
• Check that the oil reaches the lower edge of
the opening.
• Fit a new gasket and tighten the screw.
If the oil level is too low
• Top up with oil; à p. 7 - 54.
2nd axle line
The drive has two oil chambers.
• Remove the drain plugs (1) and (2).
• Check that the oil reaches the lower edge of
the openings.
• Fit new gaskets and tighten the screws.
If the oil level is too low
• Top up with oil; à p. 7 - 54.
