Maintenance work on the superstructure
8.4 Slewing gear
03.11.2017
Maintenance manual 3 302 574 en 8 - 19
GMK3060
8.4.5 Changing the oil/checking the oil – Slewing gear
transmission
• Comply also with the run-in regulations; à p. 4 - 1.
Oil, spare parts,
tools
– Receptacle, approx. 5 l (1.5 gal);
à p. 2 - 4.
Prerequisites – The truck crane is horizontal and is in on-road mode;
à Operating
Instructions
.
– The engine must not be running and must be secured against
unauthorised use;
à p. 2 - 3.
Changing the oil
s
Gear oil
in litres (gal)
Designation
to DIN 51502
Specification
Classification
GROVE part no.
0.9 (0.24) C - LPF MIL-L 2105 B
API-GL-4/5
Viscosity:
SAE 75 W-90 EP
ISO - VG 220
02313611
Synthe
tic oil; do
not mix this with
mineral-based
oils!
Designation Quantity GROVE part no.
Gasket 10 x 14 Cu DIN 7603 1 00117125
Gasket 14 x 20 Cu DIN 7603 1 00117132
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any
consumables that escape.
Stor
e/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
