Manitowoc GROVE GMK 3060 - Changing the Pollen Filter

Maintenance work on the carrier
7.16 Air-conditioning system
7 - 118 3 302 574 en Maintenance manual
GMK3060
03.11.2017
7.16.6 Changing the pollen filter
Reducing
the interval
• Under difficult operating conditions – at extremely sandy or dusty loca-
tions – you must change the filter earlier than normal.
Spare parts
and tools
Prerequisites – The engine must not be runn
ing and must be secured against unauthor-
ised use;
à p. 2 - 3.
Changing
• Open the front flap (4); à p. 7 - 2.
• Remove the frame (3).
• Remove the filter (2) from the frame and
clean the frame with a cloth.
• Insert a new filter – with the blue side (1)
facing outwards.
• Fasten the frame.
• Close the front flap; à p. 7 - 2.
M 12
Designation Quantity GROVE part no.
Filter 1 03326193
