Manitowoc GROVE GMK 3060 User Manual

Maintenance work on the carrier
7.7 Axle lines
7 - 56 3 302 574 en Maintenance manual
GMK3060
03.11.2017
7.7.5 Final drives - Changing the oil
Oil, spare parts,
tools
1)
Additional equipment (1st axle line driven).
– Drain channel.
– Receptacle, approx. 5 l (1.5 gal);
à p. 2 - 4.
Prerequisites – The truck crane must be raised on outriggers.
– The engine must not be running and must be secured against unauthor-
ised use;
à p. 2 - 3.
– The parking brake must be released.
M 12
Gear oil
in litres (gal)
Designation
to DIN 51502
Specification
Classification
GROVE part no.
for each final
drive:
1.4 (0.4)
C - LPF MIL-L 2105 B
API-GL-5
Viscosity:
Hyp SAE 90
ISO - VG 220
00552891
for drive Designation Quantity GROV
E part no.
6 x 4 x 6
Gasket 24 x 30 Cu DIN 7603
4 04181265
Gasket 16 x 20 Cu DIN 7603 4 00117134
6 x 6 x 6
1)
Gasket 24 x 30 Cu DIN 7603 6 04181265
Gasket 16 x 20 Cu DIN 7603 6 00117134
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any
consumables that escape.
Store/dispose of consumables and
any soaked equipment properly.
Ask about the applicable regulations.
