Maintenance work on the superstructure
8.4 Slewing gear
03.11.2017
Maintenance manual 3 302 574 en 8 - 21
GMK3060
8.4.6 Changing the oil/checking the oil – Slewing
gear brake
• Comply also with the run-in regulations; à p. 4 - 1.
Oil, spare parts,
tools
– Drain channel
– Receptacle, app
rox. 5 l (1.5 gal);
à p. 2 - 4.
Prerequisites – The truck crane is horizontal and is in on-road mode;
à Operating
Instructions
.
– The engine must not be running and must be secured against
unauthorised use;
à p. 2 - 3.
Changing the oil
s
Gear oil
in litres (gal)
Designation
to DIN 51502
Specification
Classification
GROVE part no.
1.0 (0.26) ATF AVIA Fluid ATF 66M
DB 236.2
(coloured in red)
01930670
Designation Quantity GROVE part no.
O-ring 23.47 x 2.62 1 03046046
O
Risk of environmental damage due to leaking consumables!
Always let consumables drain into suitable receptacles. Wipe up any
consumables that escape.
Stor
e/dispose of consumables and any soaked equipment properly.
Ask about the applicable regulations.
