Manitowoc GROVE GMK 3060 User Manual

Maintenance work on the carrier
7.8 Wheels
7 - 62 3 302 574 en Maintenance manual
GMK3060
03.11.2017
7.8.2 Checking the tyre pressure
•
Check the air pressure using the following table.
7.8.3 Checking that the wheel nuts are tight
Spare parts
and tools
– Torque wrench for
650 Nm (480 lbf ft).
W
S
Risk of damage to the tyres!
The air pressure increases when the tyres become hot during driving.
Never release the increased air pressure of tyres
at operating temperature!
Always check the air pressure in on-road driving mode with cold tyres.
Tyres Air pressure in bar (psi)
with cold tyres
14.00 R 25
385/95 R 25
10.0 (145)
16.00 R 25
445/95 R 25
9.0 (131)
20.50 R 25
525/80 R 25
7.0 (102)
all Michelin X-Crane
all Michelin X-Crane +
9.0 (131)
M 1
Designation Quantity per
wheel
GROVE part no.
Wheel nut with pressure plate
for steel rims
10 01207756
Wheel nut with pressure plate (ALCOA)
for aluminium rims
10 7659100000
Wheel nut with pressure plate (BIMECC)
for aluminium rims
10 03246867
Protective cap on the wheel nut
(only for aluminium rims)
10
80038328
