Maintenance work on the carrier
7.5 Exhaust system with exhaust emission control
03.11.2017
Maintenance manual 3 302 574 en 7 - 45
GMK3060
Renewal The maintenance periods can fluctuate greatly depending on the truck crane
operating conditions, fuel quality,
and engine oil quality.
Under good operating conditions the soot particle filter and catalytic con-
verter must be replaced after five years (Y 5), 100,000 km (62,000
mi), or
5,000 operating hours (5,000 oper. hrs.).
Service partner • Have the particulate filter and catalytic converter replaced by service
partners.
Information can be obtained from Manitowoc Crane Care.
Prerequisites – The engine must not be running and must be secured against unauthor-
ised use;
à p. 2 - 3.
– The exhaust system has cooled down.
Overview
The filters/catalytic converters (1) are located
internally in different sections of the exhaust
system.
G
Risk of burns if the exhaust system is hot!
During operation, the exhaust system can heat up to 600 °C (1,100 °F).
Wear suitable gloves and/or wait until the exhaust system has cooled
down. Be sure not to touch any hot parts.
G
Soot particles can be a health hazard!
Soot particles are suspected of being hazardous to health.
Wear appropriate dust respirator masks and be careful not to breathe in or
ingest soot particles.
O
Risk of polluting the environment!
Collect the combustion residues from the particulate filter and catalytic con-
verter in a suitable receptacle and dispose of them according to the relevant
regulations.
