Maintenance work on the superstructure
8.8 Hoist ropes
03.11.2017
Maintenance manual 3 302 574 en 8 - 53
GMK3060
Damage Description Cause Replacement
Flattening (1)
Crushed areas,
mostly with wire
breaks.
Mechanical damage,
e. g. due to driving
over the rope.
Determine number of wire
breaks; replace rope
immediately if serious crushing
has occurred.
Kink (2) Rope deformation
with twists and
wire breaks.
Rope in the eyelets
was pulled straight
while twisted.
Replace the rope immediately.
Buckling (3) Buckled section in
the rope.
Mechanical damage. Replace the rope immediately.
Crinkling (4) Crinkling rope
deformation.
Loaded rope was
pulled over an edge.
Replace the rope immediately.
