Spare parts required for maintenance
11.2 Lighting
03.11.2017
Maintenance manual 3 302 574 en 11 - 3
GMK3060
Outrigger beam spotlights:
(above the front and rear outrigger beams)
– Filament lamp
or
– Spotlight; complete
02316460
03143786
8GH 002090251
LED
70
Yellow rotating beacon:
(on the driver's cab)
– Rotating beacon, complete 04156048
Inside light:
(in the driver's cab)
– Cab light 00550434 K 24 V 10
– Reading light 00550434 K 24 V 10
SUPERSTRUCTURE LIGHTING:
Marker lights, yellow:
(left and right on the main boom head)
– Side marker light 03329569 LED
Red rear marker lights:
(on the turntable)
– Marker light 03329492 FPL 98 CKS
Yellow rotating beacon:
(on the turntable)
– Rotating beacon, complete 04156048
Inside light:
(in the crane cab)
– Cab light 00550434 K 24 V 10
– Reading light 00550434 K 24 V 10
Spotlight, angular-shaped, permanently installed:
(at the front of the crane cab)
– Filament lamp 01573349 H3 24 V 70
Spotlight, electrically adjustable:
(at the front of the main boom)
– Filament lamp 03142726 8GS009028001 35
Spotlight, swinging:
(at the front of the main boom)
– Halogen bulb 02309610 810992 RSY
100
Installation location GROVE part
number
Designation Power (W)
