MLA System USER GUIDE
MLA System User Guide V2.1 159
Add an Array
One you have selected the preferences that you wish to use, the first step is to add an array. Go to the ‘Add’ tab and click on the
array icon. The following window will appear;-
In the first drop-down you must select the type of array, either ‘None’ MLA, MLAC (MLA Compact) or 'MLAM' meaning MLA Mini.
Select MLA Mini, “None” has very limited use (perhaps for silent discos?).
Next you need to select your method of deployment which will in turn determine a number of other factors in how the design
process operates. The options for MLA and MLA Compact are flown or stack and for MLA Mini, flown with sub, ground stacked,
ground stacked on sub and pole mount;-
Next you need to select the total number of cabs. The options change according to the maximum number for each type of
deployment. For MLA and MLA Compact you can fly up to 24 cabinets;-
