MLA System USER GUIDE
MLA System User Guide V2.1 60
IP RATING IP 24
DIMENSIONS (inc. wheelboard) (W) 1126mm x (H) 607mm (607mm) x (D) 1027mm (1200mm)
(W) 44.4in x (H) 23.9in (18in) x (D) 47.2in
WEIGHT (ex. wheelboard) 160kg (352lbs)
Accessories
Flying frame (including clinometer)
Flying Pin
Mains distribution system
Tour-grade network interconnects
Merlin Controller/Unet Hub
Notes
(1) Measured on-axis in open (4) space at 4 metres, then referred to 1 metre.
(2) AES Standard ANSI S4.26-1984.
(3) Measured in half-space at 1 metre with a tone burst signal, then referred back to open (4) space.
(4) Calculated from 4m 2.83v sensitivity, referred to 1m.
